Sensors / Transmitters
View our Range of Temperature, Humidity and Co2 Sensor Transmitters with various outputs for Building Management Systems (BMS)
Contractor Log In
-
J Type Temperature Probe 3m
R708.40EVCO EVTPJ830V200 J Type Thermocouple, 3m Steel Braded Lead, 6 x 100mm Stainless Steel tip. Range 0 to 350 Deg C
Suitable for most J Type Controllers.
-
Indoor Temperature Sensor
R402.50The Trend TB/TS Wall Mounted Space Temperature Sensor has a thermister output. The Temperature Range is -10 ...... 40 deg C
-
Indoor Temperature Transmitter
R1,035.00The Trend T/PS Wall Mounted Space Temperature Transmitter Sensor has an 4-20mA output. The Temperature Range is -10 ...... 40 deg C
-
J Type Temperature Probe 1.5m
R570.40EVCO EVTPJ815V200 J Type Thermocouple, 1.5m Steel Braded Lead, 6 x 100mm Stainless Steel tip. Range 0 to 350 Deg C
Suitable for most J Type Controllers.
-
NTC Temperature Probe 1.5m
R167.90EVCO EVTPN615F200 NTC Temperature Probe, thermoplastic lead, 6 x 15mm overmoulded tip. Range -40 to 110 Deg C
Suitable for all EVCO NTC Controllers.
-
Indoor Temperature Sensor
R372.60The Vector SRA-Tn10 Indoor Wall Mounted Temperature Sensor with a NTC Probe (10k ohm @ 25 Deg C) Temperature Range is -70 ...... 150 deg C
Available in different sensor options, please see Spec Sheet for ordering codes
-
Duct/Immersion Temperature Sensor
R712.08The Vector SDB-Tn10-12-W-1 is a Duct Mounted Temperature Sensor which can also be used as an Immersion Sensor by fitting an AMI Stainess Steel Pocket (Available in different lengths)
Please see Spec Sheet for specific ordering codes
-
-
Outdoor Temperature Transmitter
R3,479.90The Vector SOC-T1-1 is an Outdoor Wall mounted Temperature Transmitter with an option of 0-10V / 4 = 20mA Output Configurable via jumpers.
-
Indoor Humidity Transmitter
R2,167.24The Vector SRC-H1-A3 Indoor Wall Mounted Humidity Transmitter has an option of 0-10V / 0-20mA / 4 -20mA Output Configurable by jumpers
-
Indoor Temperature Transmitter
R1,600.80The Vector SRC-T1 Wall Mounted Temperature Transmitter Sensor has options of 0-10V / 2-10V / 0 - 20mA / 4-20mA outputs configurable by jumpers. The Sensor Temperature Range is -40 ...... 60 deg C
-
Indoor Co2 Transmitter
R6,877.00The Vector SRC-C1 Indoor Wall Mounted Co2 Transmitter has an option of 0 - 10V / 2 - 10V / 0 -20mA / 4 -20mA Output with a 0 - 2000ppm Range
Can be used a Proportional Fresh Air Controller or Direct Control of an Extract Fan
Display module available.
